4 | 第一章: 主板介绍
1�3 主板特性
規格
CPU支援
LGA1150架構, 支援Intel® Core™ i7/ i5/ i3處理器和Intel®Pentium®處理器/
Intel® Celeron® 處理器
* 請瀏覽映泰網站 www.biostar.com.tw 獲得CPU的支援列表
晶片組 Intel® H81
記憶體
支援雙通道DDR3 1066/ 1333/ 1600
2x DDR3 DIMM插槽,支援最高容量為16GB
每根DIMM支援non-ECC 512MB/ 1/ 2/ 4/ 8 DDR3記憶體模組
* 請瀏覽映泰網站 www.biostar.com.tw 獲得記憶體的支援列表
儲存
支援AHCI
2x SATA II接頭 (3Gb/s)
2x SATA III接頭 (6Gb/s)
網路
Realtek RTL8111GSF-CG / RTL8151GSH-CG / RTL8111H-CG (colay)
10/ 100/ 1000 Mb/s 半/全雙功能,自動協商模式
音效
ALC887
5.1聲道,支援高解析音效輸出
USB
2x USB 3.0連接埠(後側面板2個連接埠)
6x USB 2.0連接埠(後側面板2個連接埠,內建接頭支援4個連接埠)
擴充插槽
1x PCIe 2.0 x1插槽
1x PCIe 2.0 x16插槽 (x16模式)
後側面板接頭
1x PS/2鍵盤連接埠
1x PS/2滑鼠連接埠
1x VGA連接埠
1x HDMI連接埠
2x USB3.2 Gen1連接埠
2x USB2.0連接埠
1x LAN連接埠
3x 音效接孔
內建接頭連接埠
2x SATA II接頭 (3Gb/s)
2x SATA III接頭 (6Gb/s)
2x USB2.0連接埠(每個接頭支援2個USB2.0連接埠)
1x 電源插槽(4-pin)
1x 電源插槽(24-pin)
1x CPU風扇接頭
1x 系统風扇接頭
1x 前置面板接頭
1x 前置音效接頭
1x 內部立體聲揚聲器接頭
1x 清除CMOS組態資料接頭
1x 序列埠接頭
主板尺寸 uATX型式規格,190 mm x 170 mm
操作系統支援
Windows 7/ 8/ 8.1/ 10
* 如有增加或減少任何OS支援,Biostar保留不預先通知的權利。
