1.3 MOTHERBOARD FEATURES
P4M900-M7 SE P4M890-M7 TE
CPU
LGA 775
Intel Core2Duo/ Pentium 4 / Pentium D /
Celeron D / Celeron 4xx processor up to 3.8
GHz
Supports Hyper Threading/ Execute Disable
Bit/ Enhanced Intel SpeedStep®/ Intel
Extended Memory 64 technology
*It is recommended to use processors with
95W power consumption.
LGA 775
Intel Core2Duo/ Pentium 4 / Pentium D /
Celeron D / Celeron 4xx processor up to 3.8
GHz
Supports Hyper Threading/ Execute Disable
Bit/ Enhanced Intel SpeedStep®/ Intel
Extended Memory 64 technology
*It is recommended to use processors with
95W power consumption.
FSB 533 / 800 / 1066 MHz 533 / 800 / 1066 MHz
Chipset
VIA P4M900
VIA VT8237A
VIA P4M890
VIA VT8237A
Graphic
Chrome9 HC 3D / 2D Graphics
Max Shared Video Memory is 256 MB
Unichrome Pro IGP
Max Shared Video Memory is 64 MB
Super I/O
ITE 8712F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
ITE 8712F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DIMM Slots x 2
Supports DDR2 533 / 667
Each DIMM supports 256/512MB/1GB/2GB
DDR2
Max Memory Capicity 4GB
Single Channel Mode DDR2 memory
module
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Supports DDR2 533
Each DIMM supports 256/512MB/1GB/2GB
DDR2
Max Memory Capicity 4GB
Single Channel Mode DDR2 memory
module
Registered DIMM and ECC DIMM is not
supported
IDE
Integrated IDE Controller
Ultra DMA 33~133 Bus Master Mode
supports PIO Mode 0~4,
Integrated IDE Controller
Ultra DMA 33~133 Bus Master Mode
supports PIO Mode 0~4,
SATA
Integrated Serial ATA Controller
Data transfer rates up to 1.5 Gb/s.
SATA Version 1.0 specification compliant.
Integrated Serial ATA Controller
Data transfer rates up to 1.5 Gb/s.
SATA Version 1.0 specification compliant.
LAN PHY
Realtek RTL 8201CL PHY/
Atheros AR8012 PHY (Optional)
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Realtek RTL 8201CL PHY/
Atheros AR8012 PHY (Optional)
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High-Definition Audio support
ALC662
5.1 channels audio out
High-Definition Audio support
