Motherboard Manual
6
1.5 MOTHERBOARD LAYOUT
Super
I/O
DIMM1
DIMM2
FDD1
PCI-EX1_1
PCI-EX16
PCI1
PCI2
JPANEL1
JUSB2
JUSB3
JATXPWR1
JCFAN1
JATXPWR2
JSATA1
JSATA2
Codec
JCDIN1
JSFAN1
BAT1
VIA
VT8237A
LGA775
CPU1
P4M900
or
P4M890
JAUDIOF1
JKBMS1
JUSB1
JUSBLAN1
COM1
JCOM1
JVGA1
IDE1
JCMOS1
LAN
IDE2
BIOS
JAUDIO1
JPRNT1
Note: ■ represents the 1
st
pin.
