Mainboard P4M900
3
Supports 360KB/ 720KB/ 1.2MB/ 1.44MB/ 2.88MB
IDE Connector:
Two IDE connectors
Supports up to four IDE devices
Supports Ultra ATA 33/66/100/133
Supports high capacity hard disk drives
Serial ATA Connector:
Two SATA connectors
Supports SATA 1.0 specification with transmit speed up to 1.5 Gbps
Supports SATA RAID 0/ 1
One SATA connector can only support one SATA HDD
Onboard LAN Chip:
10/100 Mbps Ethernet LAN supported
I/O facility Connectors
Supports one PS/2 mouse port and one PS/2 keyboard port
One multi-mode Parallel Port is capable to support as the following:
1. Standard & Bi-direction Parallel Port
2. Enhanced Parallel Port (EPP)
3. Extended Capabilities Port (ECP)
Supports one serial port (COM1)
Supports one VGA port (=D-Sub)
Universal Serial Bus:
Four onboard USB 2.0/ 1.1 ports
Two front USB headers come with this mainboard for additional four USB ports
Support a maximum of eight USB ports to connect USB compliant devices
BIOS:
Phoenix-Award™ BIOS
Support APM1.2
Support ACPI 2.0 power management
