4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset INTEL® B250
Memory
Supports Dual Channel DDR4 1866/2133/2400
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* DDR4-2400 for 7th Generaon Intel® Core™ Processor Family.
* Please refer to www.biostar.com.tw for Memory support list.
Storage 6x SATA III Connector (6Gb/s)
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
6x USB 3.0 port (4 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
TB250-BTC PRO:
11x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot
TB250-BTC+ :
7x PCIe 3.0 x1 Slot
1x PCIe 3.0 x16 Slot
* PCIe 3.0 x1 Slot : for Crypto Mining, please change the speed to PCI-E 2.0 in BIOS seng
* Maximum VGA cards mining support are depening on VGA Driver or mining soware.
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x DVI-D Port
1x LAN port
2x USB Port (only 1.5A power)
2x USB 2.0 Port
4x USB 3.0 Port
3x Audio Jack
Internal I/Os
6x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.0 Header (each header supports 2 USB 3.0 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
2x 4-Pin Power Connector (for Crypto Mining, 4pin power connector must be installed)
1x 15-Pin SATA Power Connector (for USB power enhancement)
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x COM Serial Header
1x Clear CMOS Header
Form Factor ATX Form Factor, 295mm x 210mm
OS Support
Windows 7 (32/64bit) / 8.1(64bit) /10(64bit)
* Windows 7 (32/64bit) / 8.1(64bit) for 6th Generaon Intel® Core™ Processor Family only.
* Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar TB250-BTC+ Specifications

General

Chipset	Intel B250
CPU Socket	LGA 1151
Form Factor	ATX
Memory Type	DDR4
Maximum Memory	32GB
Memory Slots	2
SATA 6Gb/s Ports	6
USB 2.0 Ports	6
Network	Realtek RTL8111H - 10/100/1000 Mb/s
RAID Support	RAID 0, 1, 5, 10
PCIe Slots	1 x PCIe 3.0 x16, 5 x PCIe 3.0 x1
Audio	Realtek ALC887 8-Channel HD
M.2 Slots	1
USB 3.0 Ports	6 (4 rear, 2 via header)
