1.3 MOTHERBOARD FEATURES
TH67+ / TH67 TH67B
CPU
Socket 1155
Inte l Core i7 / i5 / i3 / Pentium p rocess or
Supports Execute Disab le B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Inte l Core i7 / i5 / i3 / Pentium p rocess or
Supports Execute Disab le B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H67 Intel H67
Super I/O
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
ITE 8728
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main Memory
DIMM Slots x 4
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 4
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 16GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
SATA 2 & 3
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
LAN
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Sound Codec
ALC892
5.1 channels audio out
High Definition Audio
ALC892
5.1 channels audio out
High Definition Audio
USB3.0 NEC uPD720200 / Asmedia ASM1042
PCI slot x1 PCI slot x1
PCI-E Gen2 x16 @ x16 slot x1 PCI-E Gen2 x16 @ x16 slot x1
PCI-E Gen2 x16 @ x4 slot x1 PCI-E Gen2 x16 @ x4 slot x1
Slots
PCI-E Gen2 x1 slot x1 PCI-E Gen2 x1 slot x1
