35 Technical Data
Technical Data
ICS 3000: General Information
Dimensions [mm] 322*168*332 (W*H*D)
Safety class I (DIN EN 60601-1, Section 5.1
Protection degree IP 20, IEC 60529
Protection degree
for anesthetics
None; DIN EN 60601-1, Section 39
Operating mode Continuous operation
Permissible Environmental Conditions
Operation Storage
Temperature [°C] 10–40 0–50
Relative Humidity
[%]
25 – 95 35 – 75
No condensation
Air pressure [hPa] 700 – 1060
Operation Module: General Information
Dimensions [mm] 318*85*270 (W*H*D)
Weight [kg] 3,2
Operating voltage
[V]
9.6; DC
Max. power [W] 30, not including the battery charge
Average power [W] 20, not including the battery charge
Serial port 1; includes IrDA
USB port 1
Rechargeable Battery
Type NiMH (HHR-380AB L2x2+L2x2)
Voltage [V] 9,6
Capacity [Ah] 3,8
Operating time
[hrs]
1,5
Battery monitoring Gas gauge, battery level monitoring
