BIOTRONIK ICS 3000 - Symbol Index

46 Symbol Index
Symbol Index
Follow the instructions for use!
Operation Module
On/Off button
Button for displaying the battery level
Safe program button
Emergency shock button
ECG input with a BF degree of protection,
defibrillation-proof
Connection for the PGH 3000 programming head
with a B degree of protection
Programming Head
Safe program button on the PGH 3000 programming
head
Position indicator on the PGH 3000 programming head
