Chapter 2 Installation
Portability
When transporting the wattmeter, be sure the range switch is in the “off”
position. In any other switch position, there is a slight drain on the 9 V battery. If
the unit is to be inactive for more than 2 weeks, remove the battery to avoid
damage from possible battery leakage. See
"Battery Care" on page 14
.
Handle the plug-in elements with care at all times. Calibration could be
disturbed if they are dropped or subjected to hard blows.
Installing Battery
The 9 V battery is shipped separately and must be installed before operation.
Refer to figure 2 for battery location.
Figure 2 Battery Installment
Battery Access
Door
