Directional RF Thruline® Wattmeter, Series 4410
19
Figure 9 Calibration Set-Up
Sine Wave Generator
BNC "T"
Adapter
Plug-in Calibration
Device
A.C. Voltmeter
Coaxial
Cable
Coaxial
Cable
Wattmeter
Under Test
