3.4 FIREPLACE INSTALLATION
3.4.1 Locating the BIS PANORAMA
1. The best place to install your fireplace is determined by considering the location of
windows, doors, and the traffic flow in the room where the fireplace is to be located,
allowing space in front of the unit for the hearth extension and the mantel, and taking
into consideration the location of the hot air ducts (optional), outside air kit and
chimney. If possible, you should choose a location where the chimney will pass
through the house without cutting floor or roof joists (see fireplace dimensions page
17).
2. Usually, no additional floor support is needed for the fireplace. The adequacy of the
floor can be checked by first estimating the weight of the fireplace system. Weights
are given in the appendix. Next, measure the area occupied by the fireplace that is
normally 38" X 24 _". Note the floor construction and consult your local building
code to determine if additional support is needed.
3. A minimum of 7’ (2134 mm) measured from the floor to the ceiling is required to
install the BIS PANORAMA. The appliance can be installed on a combustible floor
or on a base, leaving at least 6’8" (2032 mm) from the base of the unit to the ceiling.
4. When selecting the location, the chimney outlet position and the direction of the wind
are important factor affecting the chimney performance. To allow a maximum draft
and to reduce wind turbulence, the chimney must:
• Penetrate the highest part of the roof.
• Be installed as far as possible of roof offsets, trees or any other obstructions that may
cause wind turbulence and back drafts in the chimney.
• The least amount of offsets (elbows) possible.
