3. THE FIREPLACE
3.1 INTRODUCTION
The BIS PANORAMA fireplace is an energy efficient, heat circulating, close combustion
fireplace using the catalytic technology. You will receive a lifetime of comfort and
enjoyment from your fireplace provided it is installed, maintained and operated properly.
• Please read these instructions and retain this manual for future reference.
• Before beginning the fireplace installation, consult the local authorities to obtain your
building permit and check your local building codes. Install the fireplace only as
described in these instructions and using only Security Chimneys International
components.
• The BIS PANORAMA is not intended for use with a gas log. Failure to follow these
instructions will void the certification and the warranty of the fireplace and may result
in an unsafe installation.
3.1.1 Parts Required
• Fireplace model BIS PANORAMA
• Door set
• Louver set (Del Sol, Diamante, Fiori or Luna)
• 7" diameter chimney model Secure Temp
ASHT+
, Secure Temp
S-2100+
, Nova
Temp
HT6000+
, Nova Temp
HT6103+
or ACBI manufactured by Security Chimneys
International only, including:
- Chimney lengths
- Elbows (where necessary)
- Radiation shield, Attic radiation shield
- Roof flashing
- Rain cap
- Supports (if necessary)
• 7" diameter TUBINOX (or PROJET SS) and masonry adaptor kit for masonry
applications
• Outside air kit
3.1.2 Additional Equipment (optional)
• 5" flexible venting system (central forced air kit – Not EPA approved)
• Gravity venting system
• Panel for clean face option (only with gravity venting system)
• Fireplace fan kit
