6. OPTIONS (Fireplace)
Description
:
Part No.:
Complete double ducting system including: 2 elbows 90º, 2 telescopic
lengths, 2 grill supports and 2 black grills
7B30ZK-1
Black grill with support
7B30ZO
Brass grill for 7B30ZK
7B30ZGB
Panel for clean face option
BPCF
Elbow 90º, 8" dia.
7B26ZE90
Elbow 45º, 8" dia.
7B26ZE45
Telescopic length, 8" dia.
7B26ZLA
Adjustable length, 8" dia. (2" - 5")
7B26ZL2A
Radiation shield
7B26ZR
forced air kit including: adaptor and 2 clamps (BISAF), Blower (BISZY),
Blower variable speed control (VRUW), Thermo-disk (VTU) and fan
to flex adaptor (BISAVF).
BISFWK-1
Flex adaptor and 2 clamps
BISAF
Flexible pipe 5" D.I. x 15 ft. Long
5FLEX15
Flexible pipe 5" D.I. x 30 ft. Long
5FLEX25
Blower for central forced air kit
BISZY
Blower variable speed control with decorative wall plate for (BISZY)
VRUW
Thermo-disk, on/off blower control for (BISZY)
VTU
Thermostat 24V kit (heating and cooling)
HCTW
Back draft damper
BISBD
Adaptor for fan to flexible pipe
BISAVF
Other Options:
Cast-iron corner ornaments with magnets
APPC-01
Cast-iron corner ornaments with magnets
APPCS-02
Cast-iron top ornament with magnet
APP-03
Panel for clean face option
BPCF
Heat activated on/off pre-wired fan kit
UZY3
Masonry chimney adaptor
BISPMA
7. APPENDIX
SPECIFICATIONS
Weight 385 lbs.
Height 45"
Width 38"
Depth 24 1/2"
Chimney weight ASHT+ (7" dia.): 7.8 lbs./ft.
Chimney weight S2100+ (7" dia.): 12 lbs./ft.
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe installation
Side wall: 24" (457 mm) measured from the doors edge
Ceiling: 6’ 8" (2032 mm) measured from the base of the fireplace
Fireplace enclosure: Bottom: 0"
Side: 0"
Back: 0"
Top: Do not fill the space above the fireplace with any material
Chimney: 2" (50 mm)
Mantel: 54" (1372 mm) measured from the base of the fireplace or 48" if installed with
clean face panel option (BPCF) and gravity kit.
