BIXOLON SRP-Q300 User Manual

SRP-Q300/Q302
Ver. 2.00
- 10 -
Printer Introduction
The SRP-Q300 series is a multi-functional cube 3-inch (80mm) cube Thermal Desktop
printer offering flexible mPOS receipt printing from smart devices. Supporting front-exit
printing, the SRP-Q300 series is designed to free up counters space and compliment the
latest mPOS system. The complete series includes the SRP-Q300 (mPOS Printer), SRP-
Q300B(Built-in Battery) and SRP-Q300H (B-gate mPOS hub). The cube printer is
complimented with a number of accessories to create the ultimate mPOS printing
solution.
The main features of the printer are as follows
1. Thermal Printer and B-gate
2. Low-noise thermal transfer method printing
3. Maximum 220mm/s printing speed
4. External dimensions
- SRP-Q300/302: 128 x 125 x 125(W X L X H)
- SRP-Q300H/302H: 128 x 125 x 160.2(W X L X H)
5. Charging function for USB, Ethernet, Wireless LAN, Bluetooth, mobile devices;
supports NFC, DK, CDP
6. Equipped with data buffer (receives print data even while printing)
7. Can print a range of barcodes
8. Range of printing density and selectable speed
(Controlled with virtual memory switch management)

BIXOLON SRP-Q300 Specifications

General

Type	POS printer
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Product color	Black
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
Autocutter durability	1.5 million cuts
Maximum roll diameter	80 mm
Printing media thickness	0.062 - 0.075 µm
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Wi-Fi	No
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired

Weight and Dimensions

Width	128 mm
Height	125 mm
