BIXOLON SRP-Q300 User Manual

SRP-Q300/Q302
Ver. 2.00
- 26 -
3-3 Inserting and changing the paper roll
Use paper roll that complies with the specifications
If you use a paper roll including paper core attached to paper, the paper
may not be properly recognized as paper Empty due to not proper
releasing of paper.
- When opening or closing the cover, be careful not to pinch your
fingers.
- Do not open the print head levers while the printer is printing.
The printer may be damaged.
- Change the paper When the printer is not receiving data, or data
may be lost.
- while the printer is operating, the printer head gets very hot,
so turn off the power and let it cool down completely.
The hot printer head can cause serious burns.
- This printer should be used in Front Exit orientation.
We don't guarantee any of issue by Vertical Exit orientation.
1) Open the printer cover by pulling the Open Cover lever forward.

BIXOLON SRP-Q300 Specifications

General

Type	POS printer
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Product color	Black
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
Autocutter durability	1.5 million cuts
Maximum roll diameter	80 mm
Printing media thickness	0.062 - 0.075 µm
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Wi-Fi	No
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired

Weight and Dimensions

Width	128 mm
Height	125 mm
