BIXOLON SRP-Q300 User Manual

SRP-Q300/Q302
Ver. 2.00
- 27 -
2) Remove the empty paper roll and replace with a new one as shown in the image.
3) Check the orientation of the roll paper when inserting it into the printer.
4) Pull out a small amount of paper as shown in the picture, and close the cover.
When closing the cover, hold down the center of printer cover
firmly so that paper roll is loaded correctly.

BIXOLON SRP-Q300 Specifications

General

Type	POS printer
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Product color	Black
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
Autocutter durability	1.5 million cuts
Maximum roll diameter	80 mm
Printing media thickness	0.062 - 0.075 µm
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Wi-Fi	No
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired

Weight and Dimensions

Width	128 mm
Height	125 mm
