BIXOLON SRP-Q300 User Manual

SRP-Q300/Q302
Ver. 2.00
- 38 -
8. Specifications
8-1 Printer Specifications
Printing Method
Thermal transfer printing
Dot Density
SRP-Q300: 180 dpi (7dots/mm)
SRP-Q302: 203 dpi (8dots/mm)
Printing Width
3-inch
72 mm
Roll Width
3-inch
79.5±0.5 mm
No. of Characters per Line
(Default Value)
SRP-Q300: 42 (Font A) ,56 (Font B) ,56 (Font C)
SRP-Q302: 48 (Font A) ,64 (Font B) ,64 (Font C)
Printing Speed
Max. 220 mm/sec
Receiving Buffer Size
4K bytes
Interface
SRP-Q300/302: USB, LAN, WLAN, Bluetooth,
USB charging port, NFC, LCD port
SRP-Q300H/302H: 4xUSB host, LAN,
Bluetooth, USB charging port, WLAN dongle
Drawer Kick-out Port
2port (with Y-type cable)
Card reader
MSR
ISO 7810/7811/7812, 3 track (1 & 2 & 3 track)
SCR
ISO 7816 EMV L1 / L2
AC/DC Adapter
Input Voltage
100~240 VAC
Frequency
50/60 Hz
Output Voltage
24 VDC
Environment
Condition
Temperature
Operating: 0 ~ 40 ℃
Storage: -20 ~ 60 ℃
Humidity
Operating: 10 ~ 80 % RH
Storage: 10 ~ 90 % RH
Paper excluded
Life Span
Printer Head
150 Km
Auto Cutter
1,500,000 cuts
The specifications were determined based on operation at normal
temperature using designated paper on default settings.
They are subject to change depending on temperature or printing level.
Printing speed may become slightly slower depending on
the data transmission speed and the combination of commands.

BIXOLON SRP-Q300 Specifications

General

Type	POS printer
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Product color	Black
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
Autocutter durability	1.5 million cuts
Maximum roll diameter	80 mm
Printing media thickness	0.062 - 0.075 µm
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Wi-Fi	No
USB port	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired

Weight and Dimensions

Width	128 mm
Height	125 mm
