34
ESC 2
[Name] Select 1/6-inch line spacing
[Format] ASCII ESC 2
Hex 1B 32
Decimal 27 50
[Description] Selects 1/6-inch line spacing.
ESC 3 n
[Name] Set line spacing
[Format] ASCII ESC 3 n
Hex 1B 33 n
Decimal 27 51 n
[Range] Sets the line spacing to [n X (vertical or horizontal motion unit)]
inches.
[Description] 0 ≤ n ≤ 255
ESC = n
[Name] Select peripheral device
[Format] ASCII ESC = n
Hex 1B 3D n
Decimal 27 61 n
[Range] 0 ≤ n ≤ 255
[Description] Selects the device to which the host computer sends data, using n
as follows:
Bit Off/On Hex Decimal Function
Off 00 0 Printer disabled.
0
On 01 1 Printer enabled.
1 - - - Undefined.
2 - - - Undefined.
3 - - - Undefined.
4 - - - Undefined.
5 - - - Undefined.
6 - - - Undefined.
7 - - - Undefined.
ESC ? n
[Name] Cancel user-defined characters
[Format] ASCII ESC ? n
Hex 1B 3F n
Decimal 27 63 n
[Range] 32 ≤n ≤126
[Description] Cancels user-defined characters.
35
ESC @
[Name] Initialize printer
[Format] ASCII ESC @
Hex 1B 40
Decimal 27 64
[Description] Clears the data in the print buffer and resets the printer mode to
the mode that was in effect when the power was turned on.
ESC D n1...nk NUL
[name] Set horizontal tab positions
[Format] ASCII ESC D n1...nk NUL
Hex 1B 44 n1...nk 00
Decimal 27 68 n1...nk 0
[Range] 1 ≤n ≤255
0 ≤k ≤32
[Description] Sets horizontal tab positions.
● n specifies the column number for setting a horizontal tab
position from the beginning of the line.
●k indicates the total number of horizontal tab positions to be set.
ESC E n
[Name] Turn emphasized mode on/off
[Format] ASCII ESC E n
Hex 1B 45 n
Decimal 27 69 n
[Range] 0 ≤n ≤255
[Description] Turns emphasized mode on or off.
● When the LSB of n is 0, emphasized mode is turned off.
● When the LSB of n is 1, emphasized mode is turned on.
ESC J n
[Name] Print and feed paper
[Format] ASCII ESC J n
Hex 1B 4A n
Decimal 27 74 n
[Range] 0 ≤n ≤255
[Description] Prints the data in the print buffer and feeds the paper [n X
(vertical or horizontal motion unit)] inches.
