38
ESC c 5 n
[Name] Enable/disable panel FEED buttons
[Format] ASCII ESC c 5 n
Hex 1B 63 35 n
Decimal 27 99 53 n
[Range] 0 ≤n ≤255
[Description] Enables or disables the panel buttons.
● When the LSB of n is 0, the panel FEED buttons are enabled.
● When the LSB of n is 1, the panel FEED buttons are disabled.
ESC d n
[Name] Print and feed paper n lines
[Format] ASCII ESC D n
Hex 1B 64 n
Decimal 27 100 n
[Range] 0 ≤n ≤255
[Description] Prints the data in the print buffer and feeds the paper n line.
● This command sets the print starting position to the beginning
of the line.
● This command does cot affect the line spacing set by ESC 2 or
ESC 3.
● The maximum paper feed amount is 40 inches. Even if a paper
feed amount of more than 40 inches is set, the printer feeds the
paper only 40 inches.
● When label mode is selected and a paper feed amount that
exceeds the length of one label is set, the printer feeds the
label paper to the next print starting position.
ESC t n
[Name] Select character code table.
[Format] ASCII ESC t n
Hex 1B 74 n
Decimal 27 116 n
[Range] 0 ≤n ≤5, n = 11, 255
[Description] Selects a page n from the character code table.
n Page
0 0 : PC437 [U.S.A., standard Europe]
1 1 : Katakana
2 2 : PC850 [Multilingual]
3 3 : PC860 [Portuguese]
4 4 : PC863 [Canadian-French]
5 5 : PC865 [Nordic]
11 11 : PC858 [Euro]
255 Space page
[Default] n = 0
39
ESC { n
[Name] Turns upside-down printing mode on/off
[Format] ASCII ESC { n
Hex 1B 7B n
Decimal 27 123 n
[Range] 0 ≤n ≤255
[Description] Turns upside-down printing mode on or off.
● When the LSB of n is 0, upside-down printing mode is turned off.
● When the LSB of n is 1, upside-down printing mode is turned on.
FS p n m
[Name] Print non-volatile bit image
[Format] ASCII FS p n m
Hex 1C 70 n m
Decimal 28 112 n m
[Range] 1 ≤ n ≤ 255 , 0 ≤ m ≤3 , 48 ≤ m ≤ 51
[Description] Prints a non-volatile bit image n using the mode specified by m
m Mode Vertical dot density Horizontal dot density
0,48 Normal 180 180
1,49 Double-width 180 90
2,50 Double-height 90 180
3,51 Quadruple 90 90
• n is the number of the non-volatile bit image.
(defined using the FS q command)
• m specifies the bit image mode.
FS q n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n
[Name] Define non-volatile bit image
[Format] ASCII
FS q n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n
Hex
1C 71 n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n
Decimal
28 113 n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n
[Range] 1 ≤ n ≤ 255
0 ≤ nL ≤ 255
0 ≤ xH ≤ 3 (when 1 ≤ xL+xH×256≤ 1023)
0 ≤ yL ≤ 1 (when 1≤yL+yH×256≤288)
0 ≤ d ≤ 255
k = (xL+xH×256) × (yL+yH×256)×8
Total defined data area=2M bits(256K bytes)
[Description] Define the non-volatile bit image specified by n
• n specifies the number of the defined non-volatile bit image
• xL, xH specifies(xL + xH×256)×8 dots in the horizontal direction
for the non-volatile bit image you are defining.
• yL, yH specifies (yL + yH×256)x8 dots in the vertical direction for
the non-volatile bit image you are defining.
To Next Page
