Input Characteristics
Sensitivity
Input attenuator disabled: 50mVrms (f: 10Hz ~ 50MHz), 100mVrms (f: 1Hz ~ 100MHz)
Input attenuator enabled: 0.5Vrms (f: 10Hz ~ 50MHz), 1Vrms (f: 1Hz ~ 100MHz)
Max. Input Voltage Allowed: 100Vp-p (f≤100kHz), 20Vp-p (1Hz~100MHz)
Input Impedance: R>500kΩ, C<30pF
Coupling: AC
Waveform: sine or square
Low Pass Filter: cut off frequency about 100kHz (with internal attenuation: ≤ -3dB)
with external attenuation: ≥ -30 dB (f >1MHz)
Gate Time Setting: 10ms ~ 10s continuously adjustable
Display Bits: 8 (for gate Time>5s)
Totalize Capacity: ≤ 4.29×10
9
Control Mode: manual or external gate control
Accuracy: time base error ± trigger error (when signal SNR > 40dB,
trigger error ≤ 0.3)
Time base:
Type: small TCXO
Frequency: 10MHz
Stability: ±1 × 10
-6
(22°C±5°C)
2.3 General
AC Input 198~242V or 99~121V, Frequency: 47~ 63Hz
Power Consumption: <35VA
Operating Temperature 0° to +40 °C
Operating Humidity 80% R.H
Storage Temperature -40℃ to 70℃
Dimensions (W x H x D): 255 mm x 100 mm x 370 mm (10.0 x 3.93 x 14.56 inch)
Weight: 3 kg (6.6 lbs): models 4084, 4084AWG, 4085, 4086, 4086AWG
3.5 kg (7.7 lbs) model 4087
Remote Interface RS232
Accessories included
BNC to alligator cable
BNC to BNC cable
RS232 communication cable
Power line cord
Test report
Spare fuse
Installation disk for Arbitrary Waveform Creation Software (models 4084AWG or 4086AWG only)
NOTE: Specifications and information are subject to change without notice. Please visit www.bkprecision.com for
the most current product information.
