*IDN？
*RST
*SAV {0|1|2|3|4|5|6|7|8|9|10}
*RCL {0|1|2|3|4|5|6|7|8|9|10}
SYSTem:LOCAL
SYSTem:REMOTE
5.3 Detailed description of SCPI Instructions
APPLy instructions
APPLy instructions are used to directly set the output of the function generator through the remote
interface including waveform, frequency and offset. For example, to output a sine wave of 5kHz,
3Vp-p with –2.5V DC offset, the following commands need to be sent:
“APPL:SIN 5.0E+3,3, -2.5”
Instructions of lower level can also be used:
“FUNC:SHAPE SIN”, to output a sine wave
“FREQ 5.0 E+3”, to set frequency as 5kHz
“VOLT 3.0”, to set voltage as 3 VPP
“VOLT:OFFSET -2.5”, to set output offset as -2.5 V
APPLy?
Queries the waveform, frequency, amplitude and offset of current function output. The returned data
format is:
“SIN 5.000000000000E+03, 3.000000E+00, -2.500000E+00”
OUTPUT instructions
FUNCtion:SHAPe {SINusoid|SQUare|TRIangle|UP_RAMP|DOWN_RAMP|NOISe……}
Select output waveform. 27 waveforms are available. In fixed frequency mode, each of the 27 kinds
can be selected. In other modes, only sine and square waves can be selected.
FUNCtion:SHAPe?
Check the waveform of current function output. The returned data are SIN, SQU, TRI, UP_RAMP,
etc.
FREQuency <frequency>
Set the frequency of function output
FREQuency?
Check the frequency of current main function output. The returned data unit is Hz.
Set the duty cycle of pulse output.
Duty cycle: 0.1%—99.9%, in step of 0.1% (f ≤ 10 KHz)
1%—99% in step of 1% (10 kHz < f ≤ 100 kHz), default value 20%.
PULSe:DCYCle?
