Control Mode: internal or external trigger (external: TTL level, low level P1,
high level P2)
Burst Characteristics
Waveform: sine or square
Frequency Range: same as main waveforms
Burst Counts : 1 ~ 10000 cycles
Time interval between bursts: 0.1ms ~ 800s
Control Mode: internal, single or external gated trigger
Frequency Sweep Characteristics
Waveform: sine or square
Start/Stop Freq.: same as main waveforms
Sweep Time: 1ms ~ 800s (linear), 100ms ~ 800s (log)
Sweep Mode: Linear or Logarithmic
External trigger signal frequency: DC ~ 1kHz (linear) DC~10Hz (log)
Control Mode: internal or external trigger
Rear Panel Terminals (for modulation and sweep)
Output MOD OUT
Frequency: 100μHz ~ 20kHz
Waveform: sine, square, triangle, rising/falling ramp
Amplitude: 5Vp-p ± 5%
Output Impedance: 600Ω
Modulation IN
3 Vpp = 100% Modulation
External Input Trig/FSK/Burst
Level: TTL
Main OUTput
Impedance: 50Ω
Protection: Short circuit and overload protected
State Storage Characteristics
Storage Parameters: frequency, amplitude, waveform, DC offset values, modulation
parameters
Storage Capacity: 10 user configurable stored states
Storage Time: more than 10 years
2.2 Universal Counter
Frequency Range
Frequency Measurement: 1Hz ~ 100MHz
Totalize mode: 50MHz max
