4.1.4 GENERAL CONFIGURATION
The General configuration page contains various switching and identification options.
4.1.4.1 TO DISPLAY THE GENERAL CONFIGURATION PAGE
1 Access the Zero Touch Switch Manager.
2 On the left side, click the Configuration button. See Figure 4-3.
Figure 4-3. The General configuration page
4.1.4.2 BASIC OPTIONS
Within the General configuration page you can adjust various Basic options:
• Hotkeys - Freedom II switches use and as their standard hotkeys. These can be changed if they clash with other
software or hardware within the installation (Ctrl + Shift, Alt + Shift, .Right Alt, etc.).
• Default switching mode - Determines the standard switching mode to be used at power on (All, KM + speaker, KM only, etc.).
• Mouse switching - You can enable or disable mouse switching to suit your installation requirements.
• Options port mode - Determines how the serial Options port should function. Choices are Serial control to received switching
commands from a computer or RC compatible for use with an optional remote control.
• Options port speed - When the setting above is set to Serial control, this setting allows you to choose the communication
speed (110 to 230400 baud).
• Port cycling - Determines which computer ports should be visited when the user issues an instruction (either by mouse
buttons or keyboard hotkeys + tab) to cycle to the next port. Options are Cycle all ports (even those that are not active) or Cycle
only active ports.
• Audio mixing - Allows you to route the audio channels from any (or all) computers to the user’s speakers, regardless of
which computer is currently switched through to the user console. This is useful for hearing alerts that may be sounded by
computers. Place a tick next to each computer whose audio you wish to route through to the user console at all times.
