QUICK SETUP
11
1.1 Command Summary
By using a specific ‘hot’ key sequence, you can put the Remote console keyboard into a
Command Mode. From this, you can use various keys and key combinations to tune the video
signal and generally configure the extender system. The following table summarizes the ‘hot’
key command sequences used in system configuration and video tuning.
Command Mode
Enter Command Mode
Exit Command Mode & Save
Exit Command Mode Without Save
<Left Control> + <Left Shift> + <F10>
<ESC>
<Left Control> + <ESC>
Video Channel Selection
Select Channel For Adjustment
Select BOTH Video Channels
<1>, <2>
<0>
Assisted EQ
Next Assisted EQ Setting
Previous Assisted EQ Setting
Reset EQ & Delay Values
Reset EQ Values
<Left Control> + <Page Up>
<Left Control> + <Page Down>
<Left Control> + <Home>
<Left Control> + <End>
LF/HF Equalization
Increase LF Equalization (Coarse)
Increase LF Equalization (Fine)
Decrease LF Equalization (Coarse)
Decrease LF Equalization (Fine)
Increase HF Equalization (Coarse)
Increase HF Equalization (Fine)
Decrease HF Equalization (Coarse)
Decrease HF Equalization (Fine)
<L> + <Up Arrow>
<L> + <Right Arrow>
<L> + <Down Arrow>
<L> + <Left Arrow>
<H> + <Up Arrow>
<H> + <Right Arrow>
<H> + <Down Arrow>
<H> + <Left Arrow>
Quick Skew
Toggle RED Delay (19nS)
Toggle GREEN Delay (19nS)
Toggle BLUE Delay (19nS)
<Left Control> + <R>
<Left Control> + <G>
<Left Control> + <B>
Delay (Skew)
Increase RED Delay
Increase GREEN Delay
Increase BLUE Delay
Decrease RED Delay
Decrease GREEN Delay
Decrease BLUE Delay
<R> + <Right Arrow>
<G> + <Right Arrow>
<B> + <Right Arrow>
<R> + <Left Arrow>
<G> + <Left Arrow>
<B> + <Left Arrow>
Reset Commands
Set Extender To Default State
<Left Control> + <F9>
Other Commands
Toggle Remote Unit Private Mode
USB Descriptor Transfer
Set USB KB Language ID
Disable DDC Emulation
Enable DDC Emulation
Transfer DDC from monitor to Local Unit
Enter Upgrade Mode
<Scroll Lock>
<Left Control> +<F4>
<Left Control> + <F3>
<Left Control> + <F2>
<F2>
<Left Control> + <D>
<Left Control> + <Left Shift> + <Right Shift> + <F9>
