SERVSWITCH™ BRAND CATX KVM EXTENDER FAMILY
14
2.3 Features
Members of the ServSwitch™ Brand CATx KVM Extender Series offer the following
features:
• Support for USB keyboards, mice and certain other HID devices
• Support for high video resolution for use with TFT displays:
1600x1200@60Hz over 650ft (200m)
1280x1024@75Hz over 1000ft (300m)
Higher resolutions are possible at shorter distances
• Fully integrated skew compensation allows operation with CATx cables by canceling
color shift and enhancing sharpness.
• Independent low frequency (LF) and high frequency (HF) cable equalization control
ensures optimum video tuning across different cable types.
• All control and video tuning carried out using the Remote console keyboard with
settings stored in EEPROM memory.
• Emulated DDC (Display Data Channel) on all video channels
Extender Local unit emulates a universal monitor; ensures compatibility with multi-head
graphics cards
• Transparent DDC
Remote unit reads DDC table from attached monitors, transfers and stores data in Local
Unit to support non-standard displays.
• Local Video output on all video channels
Allows dual-access operation when a local USB keyboard and mouse are connected
directly to the CPU (or via a hub)
• Local and Remote unit firmware and settings flash upgradeable via USB.
• Models available with single or dual-head video support (one CATx cable required for
each video channel).
• Status indicator LEDs on each RJ45 port.
• Small footprint chassis. Rackmount options available.
• Protection: Surge protection on each RJ45 port and PSU overvoltage detection.
• Local units are normally powered directly by the PC. Connection for optional 5V PSU.
• Transparent serial port enables any serial device to be extended (up to 19.2K Baud). The
serial port may be used to extend one device (requiring handshaking lines), or up to three
simple serial devices (no handshaking).
(ACU6022A and ACU6222A only)
• Bi-directional stereo audio (16-bit digitized) support enables high-quality, low-noise
audio extension.
(ACU6022A and ACU62222A only)
