SERVSWITCH BRAND CATX KVM EXTENDER FAMILY
20
3.3 Remote Unit Installation
To install a Remote Unit:
1. Switch off all devices.
2. Connect your USB devices and monitor(s) to the Remote Unit as shown in Figure 2.
These ports may also be attached to the CPU side of a KVM switch in
order to have a Remote CPU. However, if you are attempting to use the
extender between cascaded KVM switches this may not work. Please
contact Technical Support to discuss your application.
3. If appropriate, connect audio equipment and serial devices. Connect the audio cables as
follows:
Remote Unit Audio Device
Audio Out Speakers
Audio In (MIC) Microphone
See Appendix E: Audio/Serial Ports, page 51 for further information.
4. Connect the Primary CATx cable to the INTERCONNECT (1) socket on the front of the
Remote Unit. If required, connect the Secondary CATx cable to the INTERCONNECT
(2) socket on the front of the Remote Unit (see Figure 3).
5. Connect the 5V power supply to power the unit.
Only use the power supply originally supplied with this
equipment or a manufacturer approved replacement.
