TROUBLESHOOTING & FAQ
37
5. Troubleshooting & FAQ
5.1 Video
The image is not sharp, or is badly smeared.
Have you adjusted the video equalization? Follow the instructions on page 26.
Check the Interconnect cable between the Remote and Local Units. Is it of the
recommended type (see page 19)? Is it intact along its entire length and securely
connected at both ends? Is it wired correctly (see page 49)?
Ensure that all video connections throughout the system are attached securely.
Are you using an LCD panel? You need to adjust its clock and/or phase.
Colors appear to be separated and there are colored borders on text and icons.
Have you tuned the video signal and set delays to correct skew? Follow the
instructions on page 26. See Appendix D for advanced cabling information.
Check the Interconnect cable between the Remote and Local Units. Is it of the
recommended type (see page 19)? Is it intact along its entire length and securely
connected at both ends? Is it wired correctly (see page 49)?
You can check whether skew is a problem in your system by viewing the test card
at: ftp://ftp.blackbox.com/connectivity/ServSwitch/
.
I can’t get enough color delay to correct skew.
See Appendix D: Advanced Cabling Issues (Skew), page 48.
I can’t get rid of bright ‘ringing’ after characters.
See Appendix D: Advanced Cabling Issues (Skew), page 48.
I only need video extension – not keyboard or mouse - but I can’t get a picture.
Have you powered the Local unit? The Local Unit gets its power from the CPU
through the USB connection and it will not operate without it. Use an external 5V
PSU as described on page 22.
The maximum resolution is listed as 1600x1200. Can I use 1920x1200 or 1680x1050?
Yes. As this is an analog extender there is no inherent resolution limit. Many users
are running 1920x1200 over shorter distance. With a good low-skew cable the
range could be up to 450ft (150m).
If in doubt – please test it!
