OVERVIEW
13
Figure 1 KVM/HID extender system
Local Video Outputs
Dual Video Support
ACU6201A, ACU6222A only
Certain USB HID Devices
Remote Console
Serial and Audio
Transmission
ACU6022A, ACU6222A only
5V PSU
Remote Unit
KVM/HID extension over CATx
cables up to 1000ft (300m).
Local Unit
CPU
