41
APPENDIX B: Cable Product Codes
Appendix B: Cable Product Codes
The tables below list the product codes for all the types of CPU Adapter Cables we
currently offer for use with the ServSwitch Jr. For these cables, xxx’s are shown in
place of the last three digits of the product code because the cables come in several
stock lengths. For standard CPU Adapter Cables, these last three digits can be
“005,” “010,” or “020” for 5-foot (1.5-m), 10-foot (3-m) or 20-foot (6.1-m) cables
respectively. For coaxial CPU Adapter Cables, these last three digits can be “005,”
“010,” “020,” “035,” or “050” for 5-foot (1.5-m), 10-foot (3-m), 20-foot (6.1-m), 35-
foot (10.7-m), and 50-foot (15.2-m) cables respectively.
You’ll also see the product codes for the Station Extender and CAT5 KVM
Extender equipment listed on the next page.
Depending on your equipment and
the video resolution
you’re using, you might be able to use one of the Extender
types to connect the ServSwitch Jr. to a CPU or a monitor/keyboard/mouse station
as much as 1000 ft. (300 m) away.
If your monitor/keyboard/mouse-sharing system has cabling requirements that
can’t be met by what you see here, call Black Box for a possible quote on custom
cables or adapters.
Standard CPU Adapter Cables:
Video Type Keyboard Type Mouse Type Product Code
(Connector on Cable) (Connector on Cable) (Connector on Cable)
VGA (HD15 male) IBM PC/AT (5-pin DIN male) Serial RS-232 (DB9 female) EHN048-0xxx
VGA (HD15 male) IBM PS/2 (6-pin mini-DIN male) PS/2 (6-pin mini-DIN male) EHN051-0xxx
Coaxial CPU Adapter Cables:
Video Type Keyboard Types Mouse Types Product Code
(Connector on Cable)
VGA (HD15 male) IBM PC/AT and PS/2 RS-232 and PS/2 EHN282-0xxx
RS/6000 (13W3 male) IBM PS/2 (6-pin mini-DIN male) PS/2 (6-pin mini-DIN male) EHN520-0001
SGI (13W3 male) IBM PS/2 (6-pin mini-DIN male) PS/2 (6-pin mini-DIN male) EHN500-0xxx
