B.A Eagle Item code: BH158 Instruction Manual
12
The number of times
the same way Assembly
(in this case twice).
2
Cut off excess.
Flaslink
Pushrod
4
6mm
Bend 90
o
Nylon Clevis
Horn
Pushrod
1.7x8mm Cap Screw
4
