B.A Eagle Item code: BH158 Instruction Manual
28
INSTALLING THE STOPPER
Rubber
Rubber
Aluminum
Aluminum
30mm Screw
Bend 40
0
degree
Bend 40
0
degree
40 degree bend
40
0
40
0
9mm
12mm
6mm
!
Inflame
Do not overheat,
it may break.
WARNING
