Black Horse Model B.A. EAGLE - Part Listing ( Not Included ); Tools & Supplies Needed; Symbols Used Throughout this Instruction Manual, Comprise

B.A Eagle Item code: BH158 Instruction Manual
BATTERY
LiPo. 6S 4000-5000mAh ....... 1 Packs
Propeller: Suit with your engine.
Servo extension leads.
................. pcs. 2
320mm ...... 2pcs
ESC
ESC: 85A ....... 1 pcs.
PARTS LISTING (NOT INCLUDED).
6
Motor: Admiral GP10
Servos size: (39.9 x 20.1 x 38.1)mm.
Torque: 4.8V (7.92kg/cm), 6V(9.43 kg/cm)...7pcs
Wire cutters.
Hex Wrench.
Threadlocker
(screw cement).
Hand or
electric drill.
cm
12345678
910
Straight edge ruler.
Some more tools.
Assorted drill bits.
Masking tape.
Paper towels.
Rubbing alcohol
90° square or builder's triangle.
Screw driver
Medium C/A glue
EPOXY A
EPOXY B
30 minute epoxy.
5 minute epoxy.
Modeling knife.
2 bender plier
TOOLS & SUPPLIES NEEDED.
Engine: 15cc Gas.
NGH GT17 recommended
Cut off excess.
BA
Apply epoxy glue.
Apply threadlocker
(screw cement).
C.A
Apply instant glue
(C.A glue, super glue).
Cut off shaded portion
carefully.
Assemble left and right
sides the same way.
Must be purchased
separately!
Ensure smooth, non-binding
movement when assembling.
Warning!
Set all scerws securely. If they come off during
flight you will lose control of your aircraft!
Pay close attention here.
Drill holes using the stated.
(in this case 1.5mm ).
1.5mm
Take particular care here.
The number of times
the same way Assembly
(in this case twice).
2
Symbols used throughout this instruction manual, comprise:
