Black Horse Model B.A. EAGLE - Installing the Main Gear

B.A Eagle Item code: BH158 Instruction Manual
INSTALLING THE MAIN GEAR.
13
Cut off shaded portion
<Bottom view>
4mm Spring Washer
- - - - - - - - - - 8
4x15mm Cap Screw
- - - - - - - 8
4mm Flat Washer
- - - - - - - - - 8
- - - - - - - - 2
- - - - - - - - - - - - - 4
6x55mm Socket Head
Cap Screw
Collar
3x15mm Tp Screw
- - - - - - - - 6
- - - - - - - - 2
4mm Hex Nut
4x15mm Cap Screw
4mm Flat Washer
6mm Flat Washer
