Black Horse Model B.A. EAGLE - Installing Horizontal Stabilizer

B.A Eagle Item code: BH158 Instruction Manual
19
Main wing must be inserted
and attached completely
before xing with screw.
INSTALLING HORIZONTAL STABILIZER
Cut off shaded portion
1.7 x 800mm Push rod
- - - - 2
- - - - - - - - - - 1
Flaslink
- - - - - - - - - - 1
Duo rod connection lock
- - - - - - - - - - 2
Horn
- - - - - - - 2
Nylon Clevis
<Top view>
