B.A Eagle Item code: BH158 Instruction Manual
20
C.A
Apply instant glue
(C.A glue, super glue).
Temporary pin to
keep hinge centered.
1) Test fit the ailerons to the wing with the hinges. If
the hinges don’t remain centered, stick a pin through
the middle of the hinge to hold it in position.
2) Apply drops of thin CA to the top and bottom of
each hinge. Do not use CA accelerator. After the CA
has fully hardened, test the hinges by pulling on the
aileron.
Secure nylon hinges with instant glue, being
careful not to glue the wing and aileron together.
Align the center line of main wing with aileron.
1
2
Warning!
Make certain the hinges are
adequately secured with glue. if they come loose in
flight accidents may result.
1
2
C . A
C . A
C.A
Ensure smooth, non-binding
movement when assembling.
<Top view>
