Black Horse Model B.A. EAGLE - Installing the Electric Motor (EP Version)

B.A Eagle Item code: BH158 Instruction Manual
33
Apply threadlocker
(screw cement).
Must be purchased
separately!
Switch
Fuel tank
Receiver
Battery
Switch
ON
OFF
10x5mm Plastic
M4 Blind Nut
4mm Flat washer
4mm Spring washer
4x20mm Socket head cap screw
- - - - - 4
10x50mm Plastic
10x5mm Plastic
M4 Blind Nut
- - - - - - - 4
- - 4
4x20mm Socket Head
Cap Screw
4mm Flat washer
4mm Flat washer
- - - - - 4- - -
- - - - - 8- - -
4mm Spring washer
- - - - - 8- - -
- - - - - 4
- - 4
4x70mm Socket Head
Cap Screw
<Fuselage top view>
INSTALLING THE ELECTRIC MOTOR (EP VERSION)
