B.A Eagle Item code: BH158 Instruction Manual
40
192mm
31mm
31mm
52mm
Wheel 35mm
74mm
28mm
MAIN GEAR DIMENSIONAL DETAIL
TAIL GEAR DIMENSIONAL DETAIL
85mm
