B.A Eagle Item code: BH158 Instruction Manual
34
Battery
Fuel tank
ESC
ESC
4mm Flat washer
4mm Flat washer
4mm Spring washer
4x70mm Socket Head Cap Screw
10x50mm Plastic
Battery
ESC
183mm
<Fuselage top view>
INSTALLING COCKPIT FUSELAGE
