Black Horse Model B.A. EAGLE - Page 22

B.A Eagle Item code: BH158 Instruction Manual
22
The number of times
the same way Assembly
(in this case twice).
2
<Bottom view>
Rudder ServoThrottle Servo
Rudder Servo
6mm
Servo arm
Push rod
Bend 90º
Flaslink
Cut off excess.
2
Horn
Nylon ClevisPushrod
1.7x8mm Cap Screw
