96
E x terior E q uip m ent
Helm and Passenger Seats
The seats are equipped with a ip up bolster that
converts each seat to a raised seating position
and allows the operator and passenger to select
the standard seating height or a higher position
for better visibility. The bolsters also provides
more room between the seat and console area
for standing when desired. To convert the seat
to the raised cushion position, lift the front of the
seat cushion to raise the bolster and push it back
above the seat cushion.
An armrest built into each seat backrest swings
up into to the backrest cushion to make it easier
to enter and exit the seat area.
Helm and Passenger Seat Storage
Compartments
There is a storage compartment that drains to the
bridge deck located below the helm and passenger
seats. The compartment hatches are recessed
and secured with push to close latches.
Rear Bench Seat
Your boat is equipped with a forward facing
bench seat in the rear of the cockpit. The seat is
designed to fold ush against the cockpit when it
is not in use.
To use the seat, pull the handle near the top of
the seat base out of the recess toward the cock-
pit. The side supports move out with the seat as
it rotates out. When the seat is half way out, lift
Helm Seat Bolster Down Helm Seat Bolster Up
the rear of the seat with one hand while pushing
the front of the seat down with the other hand
until it stops in the seat position. Then raise the
backrest.
To store the seat, lift the front of the seat until it
rotates to the half closed position. Then push the
top of the seat rmly into the recess. The seat
will automatically be secured in the stored posi-
tion when it is completely folded into the recess.
Rear Bench Seat
