Developer Information
18
Initial Status Dump
The next two blocks enumerate the labels assigned to the input and output ports.
INPUT LABELS:↵
0 VTR 1↵
1 VTR 2↵
…
↵
OUTPUT LABELS:↵
0 Output feed 1↵
1 Output feed 2↵
…
↵
Note: Input and Output labels are always numbered starting at zero in the protocol which matches
port one on the chassis.
The next three blocks describe the routing of the view ports.
VIDEO OUTPUT ROUTING:↵
0 5↵
1 3↵
…
↵
The next block describes the locking status of the views. Each port has a lock status of “O” for ports
that are owned by the current client (i.e., locked from the same IP address), “L” for ports that are
locked from a different client, or “U” for unlocked.
VIDEO OUTPUT LOCKS:↵
0 U↵
1 U↵
…
↵
