BLACKMER HD161A - Tool List

CB9A-020 page 10
MAINTENANCE
TOOL LIST
Description Used For:
Blackmer Packing Installation Tool
790536 for 160, 340, & 360 series
790538 for 600 series compressors
Rod-packing protection during installation.
Blackmer Wrench 790535 Valve Hold-down screw
3" Adjustable Spanner with 1/4" pins
(like Blackmer PN 790316)
Piston Nut, Piston,
Packing Box Hold-down Ring
9/16, 5/8 or 3/4" End Wrench Cylinder and Crosshead Guide
1-1/16" Wrench or Socket Valve Caps
3/16" Allen Wrench
7/16", 1/2", 9/16", 3/4", 5/8", 3/4",
7/8" & 1-3/8" Sockets
Various
Internal Snap Ring Pliers Seal Replacement
Feeler gauges or Depth Micrometer Piston Clearance
Screwdriver, Flat Blade Nameplate screws, Packing Installation
Pliers
Rubber Mallet
Arbor Press Wrist Pin Removal
Bearing Puller Crankshaft Bearings
Torque Wrench, 0 to 45 ft-lb range Various
Hoist (useful) Cylinder and Crosshead Guide
BOLT TORQUES
Proper bolt torques to use when reassembling the compressor.
BOLT TORQUE FOR BLACKMER COMPRESSORS FT-LBS (Nm)
Size
Con.
Rod
Bolt
Bearing
Carrier
Bearing
Cover
Plate
Crank
Case
Inspec.
Plate
Cross
Head
Guide
Cylinder Head Valve
Assy.
Nut
Valve
Cover
Plate
Valve
Hold
Down
Screw
160
30
(40.7)
30
(40.7)
35
(47.5)
7
(9.5)
25
(33.9)
25
(33.9)
20
(27.1)
-- -- 40
(54.2)
360
35
(47.5)
30
(40.7)
35
(47.5)
7
(9.5)
35
(47.5)
35
(47.5)
40
(54.2)
10
(13.6)
35
(47.5)
40
(54.2)
600
45
(61.0
30
(40.7)
40
(54.2)
7
(9.5)
40
(54.2)
40
(54.2)
40
(54.2)
10
(13.6)
35
(47.5)
40
(54.2)
