CB9A-020 page 2
GENERAL INFORMATION
COMPRESSOR DATA
Air Cooled
Single-Seal Models
Double-Seal Models
Triple-Seal Models
HD161A
HD162A
HD163A
HD361A
HD362A
HD363A
HD601A
HD602A
HD603A
Displacement
@ 350 rpm - CFM (m
3
/hr)
@ 825 rpm - CFM (m
3
/hr)
7.16 (12.2)
16.9 (28.7)
15.3 (26.0)
36.0 (61.2)
27.2 (46.3)
64.2 (109.0)
Max. BHP (kw) 10 (7.5) 15 (11) 40 (30)
MAWP - psia (kPa) 350 (2,413)
Maximum Discharge Temperature
350°F (176°C)
Type: Single-stage, vertical, air-cooled reciprocating with single acting cylinders.
NOTE: Reduce maximum speeds by 9% for continuous duty operation.
NAMEPLATE DATA
A nameplate is attached to the
side of all Blackmer compressors
showing the Model No., I.D. No.,
and Serial No. These numbers
should be available when
information or parts are needed
for a particular unit.
Model No. Indicates the basic
size and type of the compressor.
A suffix letter is used on most models to indicate the version.
I.D. No. An 11 character code identifies the construction of the compressor. A key to the I.D. Number is found
on the next page.
Serial No. 6 digits and a suffix letter indicating the year of manufacture.
Suffix L M N P Q R S
Year 1991 1992 1993 1994 1995 1996 1997
