ENGLISH
13
Imported by Black & Decker (U.S.) Inc.,
701 E. Joppa Rd.
Towson, MD 21286
BlackandDecker.com
1-800-544-6986
PROBLEM
Trimmer runs slowly.
EASYFEED
TM
does not feed more line.
Line unravels when cap or spool is removed.
SOLUTION
• Remove battery from trimmer.
• Check that the spool housing can rotate freely. Carefully
clean it if necessary.
• Check that the cutting line does not protrude more than
approximately 4-13/16 inches (122mm) from the spool.
• If it does, cut it off so that it just reaches the line
trimmingblade.
• Keep the tabs depressed and remove the spool from the
spool housing in the trimmer head.
• Ensure that the line is not crisscrossed on the spool as
detailed in Figure U. If it is, unwind the cutting line, then
wind it back on the spool neatly so that the lines do
not cross.
• Inspect tracks at the bottom of spool for damage. If
damaged, replace spool.
• Pull the cutting line until it protrudes approximately
4-13/16 inches (122mm) from the spool. If insufficient
cutting line is left on the spool, install a new spool of
cutting line.
• Align the tabs on the spool cap with the cut outs in the
housing.
• Push the spool cap onto the housing until it snaps
securely into place.
• If the cutting line protrudes beyond the trimming
blade, cut it off so that it just reaches the blade. If the
automatic line feed still does not work or the spool is
jammed, try the following suggestions:
• Carefully clean the spool and housing.
• Make sure you are using correct line shape and diameter
(0.080 inch (2.032 mm) ROUND) - other diameters and
shapes will affect the functionality of the auto feed system.
• Remove the spool and check if the lever in the spool
housing can move freely.
• Remove the spool and unwind the cutting line, then wind
it on neatly again. Replace the spool into the housing.
• Make sure to park the lines in holding slots (figure Q)
before removing.
TROUBLESHOOTING
