Components of OBD Device
Components of OBD Device (※OBD Optional Components)
• Black Box Connection Jack : Connection jack which connect with function of OBD terminal (CarNSys) and permanent power.
• Fixed device : A device for fixing a vehicle OBD terminal and an OBD terminal (CarNSys) main device.
• Operation Status LED :
- Blue lighting : Vehicle identification and normal operation status - Blue blinking : Unidentified vehicle
- Red blinking : Defective terminal - Pink blinking : Detection of vehicle malfunction
• Terminal for connecting PCs : Currently disabled
Black Box Connection Jack
(Permanent power included)
Terminal main device
Terminal for connecting PCs
(Disable)
Fixed device
Operation Status LED
