fig.1
DIMENSIONS FOR INSTALLATION USE
•
•
CHOICE OF LOCATION
The above diagrams show the dimensions of a cabinet that will be
able to hold your oven.
The oven can be installed in a cabinet column (open* or closed)
that has the appropriate dimensions for built-in installation (see
diagram opposite).
Your oven has optimised air circulation that allows it to achieve re-
markable cooking and cleaning results if the following guidelines
are followed:
•Centre the oven in the unit so as to ensure a minimum distance of
10 mm between the appliance and the surrounding unit.
•The material of the unit supporting the appliance must be heat-
resistant (or covered with a heat-resistant material).
•For greater stability, attach the oven to the unit with 2 screws
through the holes provided on the side panels. (fig.1).
*
