2
INSTALLATION OF A METAL AIR DISTRIBUTION BOX ON THE MOUNTING SURFACE
The air distribution box is designed for wall, floor, and ceiling mounting.
Fix the air distribution box to the mounting surface using bolts or threaded rods (not included in the delivery set).
While choosing fasteners consider the material of the mounting surface and the unit weight.
3
MOUNTING OF PLUGS PRF 63, PRF 75, PRF 90
Before installation, make sure that the plugs are sealed.
Install the plugs into the openings not to be used for flange connection.
Insert the plug into the slotted hole and turn it clockwise so that the closed lock symbol on the plug is opposite the arrow
on the casing.
