28
blaubergventilatoren.de
FLOORMOUNTED METAL CONNECTORS
Mounting of the connector into the slab with concrete casting
1
Make markings on the non-removable formwork of the slab for fixing holes. Use the connector as a template.
2
Drill holes according to the marking and fix the
connector to the surface.
3
Remove the lock rings from the flanges (supplied with
the flanges).
