24
blaubergventilatoren.de
CEILINGMOUNTED METAL CONNECTORS
Ceiling mounting of the connector
1
Use the connector casing to mark and drill holes for
fixing.
2
Fasten the connector to the ceiling.
While choosing fasteners (to be purchased separately)
consider the material of the mounting surface as well as the
weigh of the unit.
3
Lay the air ducts by securing them under the ceiling
with mounting tape.
4
Place two seals on each duct end on the flange
connection side.
