Blaupunkt Canberra C31 User Manual

26
1 Button, to unlock the remova-
ble control panel (release panel)
2 BAND button (Band), to switch
to radio mode,
to select the FM memory levels
and the MW and LW frequency
ranges (MW and LW are not
available on the Freiburg C31
and Las Vegas DJ31)
TS, to start the Travelstore func-
tion
FMT button (Freiburg C31 and
Las Vegas DJ31), to select the
FM memory levels,
to switch to radio mode,
to start the Travelstore function.
3 RDS button, to switch the RDS
function on/off (Radio Data Sys-
tem).
To display scrolling text.
4 SCAN button, to start the scan
function.
5 Cassette eject
6 Cassette compartment
7
button, to switch the tape
side
8 X-BASS button, to activate the
X-Bass function.
OPERATING ELEMENTS
9 CD•C button, to select radio,
cassette, CD changer (if con-
nected) and AUX sources
: AUDIO button, to adjust the
bass, treble, balance and fader
settings.
; Arrow buttons
< MENU button, to open the basic
settings menu,
, to display the time
= Keys 1 - 5
> TRAF button (traffic), to switch
traffic information standby on/off
PTY, to switch the PTY function
on/off
? Volume control
, to increase the volume
, to decrease the volume
@ Button to switch the unit on/off,
to mute the volume

Blaupunkt Canberra C31 Specifications

Amplifier

output power sine	4 x 25 watts
output power max	4 x 45 watts
voltage	14.4 V

Tuner

FM frequency range	87.5 - 108 MHz
MW frequency range	531 - 1, 602 kHz
LW frequency range	153 - 279 kHz

Frequency Response

FM frequency response	35 - 16, 000 Hz
cassette frequency response	30 - 18, 000 Hz

Inputs and Outputs

pre-amp out channels	4 channels
pre-amp out voltage	3 V
AUX input sensitivity	2 V / 6 kΩ
Tel./Navi input sensitivity	10 V / 1 kΩ
